1092mm Multi-Dryer Five Cylinder Mould Grey Cardboard Machine

  • Raw material:Waste paper
  • Output paper:Duplex board paper,grey paper, cardboard paper
  • Net paper width:1200mm
  • Paper weight:300-600g/㎡
  • Capacity:18-20T/D

We are here to help:Easy ways to get the answers you need.

PRODUCT LIST

Toilet paper machine
Toilet paper processing machinery
Culture paper machine
Kraft/Corrugated paper machine
Specialty paper machine
Paper completed section
Paper machine supporting machine
Egg tray machine
Pulping equipment

Describe

  ◆ Brief Introduction
The paper board successfully solves the difficult problem of the comprehensive utilization of paper sludge, transforms the waste into products, solves the problem that the environmental protection input is not output, and obtains good economic benefit and environmental benefit.
In the sludge can produce different thickness of cardboard, cardboard size can be customized according to customer requirements, can replace the wood and straw on the market of MDF, market prospect is very wide.
The duty to be produced by the equipment can be dried by itself, and can be matched with the pressure drying machine.

◆ Technical Parameter

Raw material

Waste paper
Output paper Duplex board paper,grey paper, cardboard paper
Net paper width 1200mm
Paper weight 300-600g/㎡
Capacity 18-20T/D
Rail gauge 1800mm
Designed speed 60m/min
Working speed 25m/min
Density of wire 0.33-0.4%
Paper dryness of wire part 15-18%
Paper dryness of press part 30-38%
Dryness of finish paper 95%
Arrange mode left and right hand machine
Drive AC Frequency conversion, section drive
