1092 Type Capacity 3-4tons Writing Paper Machine
- Raw material:Wood pulp board, virgin pulp
- Output paper:Cultural paper, writing paper
- Paper weight:45-80gsm
- Paper Width:1200mm
- Capacity:3-4 T/D
We are here to help:Easy ways to get the answers you need.
- Culture paper machine
-
- 2400mm Type Fourdrinier Multi-Dryer Newspaper Machine
- 2800mm Daily Capacity 40 Tons Fourdriner Culture Paper Machine
- 1575 Fourdrinier Cultural Paper Machine
- 1092 Type Capacity 3-4tons Writing Paper Machine
- 6-8tons culture paper machine
- 1092mm Fourdrinier Paper Making Machine
- 1092 Type Capacity 5tons Culture Paper Machine
- 787mm Type Culture Paper Machine
- 1575mm type culture paper making machine
- Specialty paper machine
-
- 1600A Model Kraft Paper Slitting Machine
- 1760mm Multi-Dryer Five Cylinder Mould Grey Cardboard Machine
- 1092mm Multi-Dryer Five Cylinder Mould Grey Cardboard Machine
- 2100mm Multi-Dryer Five Cylinder Mould Paperboard Machine
- 4 Heads CNC Spiral Paper Tube Machine
- 2 Heads CNC Spiral Paper Tube Machine
- Capacity 5-8 Per Day Paperboard Machine
Describe
| Raw material | Wood pulp board, virgin pulp |
| Output paper | Cultural paper, writing paper |
| Paper weight | 45-80gsm |
| Paper Width | 1200mm |
| Capacity | 3-4 T/D |
| Cylinder mould width | 1450mm |
| Rail guage | 1800mm |
| Driven way |
AC frequency conversion, section drive |
◆ Main Parts Of Paper Making Machine
1. Cylinder part: Cylinder mould 2 sets, back roll coated with rubber 1 pc, couch roll 2 pcs
2. Pressure part: Stone roll 1 set, rubber roll 1 set, pneumatic loading device
3. Dryer part: Dryer can 2 sets, touch roll 1 sets, couch roll 1 set, double-layer dryer can exhaust hood 1 set, axial flow fan 1 pc, pneumatic loading device
4. Calender part: 3-roll calender 1 set
5. Winding part: Winding machine 1 set
◆ Buying Guides
In order to make you an exact quotation, please tell me the follow information:
1. The paper you want to produce?
2. The raw material you use?
3. The capacity you want t produce per day?
4. The paper grammage you require?
5. The paper width you require?
