6-8tons culture paper machine
- Raw material:Waste paper, wood pulp board
- Output paper:Cultural paper
- Net paper width:1300mm
- Paper weight:60-120g/㎡
- Capacity:6-8T/D
We are here to help:Easy ways to get the answers you need.
- Culture paper machine
-
- 2400mm Type Fourdrinier Multi-Dryer Newspaper Machine
- 2800mm Daily Capacity 40 Tons Fourdriner Culture Paper Machine
- 1575 Fourdrinier Cultural Paper Machine
- 1092 Type Capacity 3-4tons Writing Paper Machine
- 6-8tons culture paper machine
- 1092mm Fourdrinier Paper Making Machine
- 1092 Type Capacity 5tons Culture Paper Machine
- 787mm Type Culture Paper Machine
- 1575mm type culture paper making machine
- Specialty paper machine
-
- 1600A Model Kraft Paper Slitting Machine
- 1760mm Multi-Dryer Five Cylinder Mould Grey Cardboard Machine
- 1092mm Multi-Dryer Five Cylinder Mould Grey Cardboard Machine
- 2100mm Multi-Dryer Five Cylinder Mould Paperboard Machine
- 4 Heads CNC Spiral Paper Tube Machine
- 2 Heads CNC Spiral Paper Tube Machine
- Capacity 5-8 Per Day Paperboard Machine
Describe
◆ Brief Introduction
This production line can use waste paper ,virgin pulp to make A4 paper, finished product can be paper roll and paper
sheet, it including followig section:
1. Pulp making production line;
2. Paper making production line;
3. Paper converting section;
4. Boiler section ;
◆ Technical Parameter
| Raw material | Waste paper, wood pulp board |
| Output paper | Cultural paper |
| Net paper width | 1300mm |
| Paper weight | 60-120g/㎡ |
| Capacity | 6-8T/D |
| Rail gauge | 1900mm |
| Drive | AC Frequency conversion, section drive |
| Cylinder mould width | 1550mm |
◆ Features
1.PLC (computer) control production, degree of full-automatic of production process is high, the function of machine is complete, and production efficiency is high.
2. Load and change the core, spray glue, seal can be done without stop the machine. When changing the core, the machine will low the speed and up the speed automatically.
3. When change the core to rewind, it will be tight first and then loose, to avoid the core loose.
4. Equipped with automatic alarm to indicate filling up of core pipe. The machine will be automatically stopped when there is no core pipes.
